Atlapex Tyre Protection Chain
A tire protection chain (TPC) is a tight and flexible metal mesh covering the tread and sidewalls of the tire to form a barrier against tire damages through punctures, cut and excessive abrasion by sharp-edged rocks and other objects.
PC is mainly used on wheel loaders and dump trucks working for most harsh environment in below operations:
• Open pit and underground Mining
• Quarrying
• Hot slag handling
• Scrap recycling
• Others (where poor traction, high abrasive or tire piercing objects are serious problems)
Benefit of using Atlapex tire protection chains
Atlapex tire protection chain is designed to save your money, it has been proven to be a high performance and most cost effective option to expensive European tire protection chain makers.
We believe that you will find what the Atlapex tire protection chain is worth using, it will brings you a substantial saving if you use it.
The sizes listed as following are for reference only and varies according to the different types of protection chains in use and site operation conditions.
Size | Ring | Link | Net WT | Usage |
kg/pc | ||||
10.00-20 | Φ 12mm | 101F | 136 | normal work |
Φ 12mm | 301BF | 168 | hot slag | |
12.00-20 | Φ 12mm | 101F | 155 | normal work |
Φ 12mm | 301BF | 195 | hot slag | |
16/70-20 | Φ 12mm | 101F | 142 | normal work |
Φ 12mm | 301BF | 186 | hot slag | |
17.5-25 L3 | Φ 12mm | 101F | 206 | normal work |
Φ14mm | 101F | 222 | hard work | |
Φ14mm | 301BF | 270 | hot slag | |
20.5-25 L3 | Φ12mm | 101F | 262 | normal work |
Φ16mm | 201F | 386 | hard work | |
Φ14mm | 301BF | 352 | hot slag | |
18.00-25 L3 | Φ12mm | 101F | 316 | normal work |
Φ16mm | 201F | 412 | hard work | |
Φ14mm | 301BF | 417 | hot slag | |
23.5-25 L3 | Φ12mm | 101F | 345 | normal work |
Φ16mm | 201F | 456 | hard work | |
Φ14mm | 301BF | 458 | hot slag | |
26.5-25 L3 | Φ14mm | 101F | 472 | normal work |
Φ16mm | 201F | 532 | hard work | |
Φ14mm | 301BF | 572 | hot slag | |
29.5-25 L5 | Φ16mm | 201F | 716 | normal work |
Φ18mm | 301F | 912 | hard work | |
Φ14mm | 301BF | 756 | hot slag | |
29.5-29 L5 | Φ16mm | 201F | 798 | normal work |
Φ18mm | 301F | 1028 | hard work | |
Φ14mm | 301BF | 802 | hot slag | |
35/65-33 L5 | Φ16mm | 201F | 886 | normal work |
Φ18mm | 301F | 1152 | hard work | |
Φ14mm | 301BF | 886 | hot slag | |
45/65-45 L5 | Φ18mm | 301F | 1940 | normal work |
Φ20mm | 401F | 2322 | hard work | |
Φ18mm | 401BF | 2438 | hot slag |
